TBoat Series

Unmanned Surface Vehicle

Bathymetric Survey | Water Quality Monitoring | Water Quality Sampling | Water Surface Inspection | Water Surface Inspection | Underwater Surveying

GNSS Receiver Manufacturer
Professional OEM&ODM
Over 15 years experience in R&D and manufacturing

System Architecture

Application Area

TBoat10-A

Bathymetric Survey

TBoat10-B

Water Quality Monitoring

TBoat10-C

Water Quality Sampling

TBoat10-D

Patrol USV with Side-scan sonar

System Architecture

Application Area

TBoat20-A

Bathymetric Survey

TBoat20-B

Water Quality Monitoring

TBoat20-C

Water Quality Sampling

TBoat20-D

Patrol USV with Side-scan sonar

TBoat20-E

Water Surface Inspection

TBoat20-F

Underwater Surveying

Hardware Parameters

Hull

Hull Dimensions:

980*520*254mm(TBoat10)

1280*580*430mm(TBoat20)

Hull Type:

Full-curve M-type monohull

Material:

Polyester Carbon Fiber Composite, Kevlar Fabric

Self-weight:

Hull: 7kg, Total: 30kg(TBoat10)

Hull: 12kg, Total: 40kg(TBoat20)

Video:

360° omnidirectional night vision camera

Remote Control

Dimensions:

277*138*96mm

Resolution:

1920*1200

Memory:

RAM: 4GB,

Storage: 64GB

Battery Capacity:

20000mAh，8 hours

Power

Motor Type:

Brushless motor

Motor Power:

Rated Power 900W(TBoat10)
Rated Power 1200W(TBoat20)

Motor Speed:

Rated 5300 RPM(TBoat10)
Rated 7000 RPM(TBoat20)

Battery Specifications:

33.6V 25Ah*2(TBoat10)
33.6V 30Ah*2(TBoat20)

rechargeable ternary lithium battery

Range at economical speed:

38km

Maximum Speed

(TBoat10):

7 m/s, supports safe passage through 4 m/s current cross-sections

Maximum Speed

(TBoat20):

6 m/s

Depth measurement

Frequency:

Beam Angle:

200 kHz

8°(TBoat10), 5°±1°(TBoat20)

Depth Range:

0.15-200m(TBoat10)

0.15-300m(TBoat20)
(Extended range available as an option)

Depth Measurement Accuracy:

±1 cm + 0.1% D (Where D is the water depth value)
